EMAX BL2820 (920KV) Outrunner Brushless Motors 4S Lipo 12x4 prop


$26.74

Add to Cart:


  • Description
  • Details
  • Reviews
4S Lipo REQ

EMAX BL2820 (920KV) Outrunner Brushless Motors
It is the high torque brushless motor with rotating drum and high power magnets suitable for models of 400-500 size, and up to 1200g in weight. The hardened steel 5mm diameter shaft and is supported by three ball bearings. Due to it's high torque characteristics this motor is capable of turning large propellers with a high level of efficiency and without the need for a gearbox.
-No. Of cells 3-4x Li-Poly
-Max. efficiency 80%
-Max. efficiency current 20- 30 A (>75%)
-No load current / 10 V 2,1 A
-Current capacity 40 A/60s
-Dimensions 38x42 mm
-Shaft diameter 5 mm
-Weight 144 g/5.07oz.
-Recomended model weight 1200-1600 g
-Recomended prop without gearbox 10"-12"
- EMAX BL2820 Outrunner Brushless Motors x 1
  • 100 Units in Stock

Be the first to write a review.  Write a Review.
