BW Thermal uncooled infrared vanadium oxide Camera 640×512
BW Thermal uncooled infrared vanadium oxide Camera 640×512
BW Thermal uncooled infrared vanadium oxide Camera 640×512
×
larger image
Features
uncooled infrared vanadium oxide Camera 640×512 white heat
Product Details
Pixel Pitch 12um
Spectral Band: 8-14μm
NETD: ≤40mK
Frame rate: 50Hz Shutter Stepless shutter
Focusing Adjustable focus
Aperture 1
Lens millimeters 6.8mm/9mm
FOV(H*V): 62.9°×49.9° / 48.9°×39.1°
output: PAL CVBS
voltage: 4.5-18V
power: 1000mw
Pseudo color White heat
weight: 55.6 grams
size : 28*28MM
Working temperature: -40℃~+80℃
Write Review
100 Units in Stock
Ask a Question
$1,800.00
Add to Cart:
Add to Cart
Notifications
Notify me of updates to
BW Thermal uncooled infrared vanadium oxide Camera 640×512
This product was added to our catalog on Monday 21 July, 2025.
